Characteristics:
good thermal shock resistance; good insulation mechanical strength; good friction resistance; good surface lubrication; Main applications: general industrial motor coils; open household motor coils; transformer coils; magnetic coils; small motor coils
| Product Name | Type | Thermal Classs | Diameter Range | China Standard (GB) | NEMA Standard | IEC Standard |
| Polyester Enameled Round Aluminum Wire |
PEW | 130 ° 155 ° 180 ° | 0.16-5.00 MM | GB/T 6109.1 |
MW30 |
IEC 60317-0-1, 2 |
| Polyamide-imide Composite Polyester Enameled Aluminum Round Wire |
PEW-NY | 155 ° | 0.16-5.00 MM |
GB/T 6109.5 | MW 35 | IEC 60317-13 |
| Polyurethane Enameled Round Aluminum Wire |
UEW | 155° 180 ° | 0.16-5.00 MM | GB/T 6109.3 | MW80/ MW82 | IEC60317-11,12 |
| Self-Bonding Enameled Round Aluminum Wire |
SB | 220 ° | 0.16-5.00 MM | GB/T 6109.12 | MW 1000 series | IEC 60317-18, 51, 60 |
| Polyamide-imide Composite Polyester-imide Enameled Aluminum Round Wire |
EI/AI | 180° 200 ° 220 ° | 0.16-5.00 MM | GB/T 6109.6
GB/T 6109.8 | MW35C
MW36 | IEC60317-29, 32 |
